Port Hole Sight Glass Kit

  • $ 40499


Our 6" x 8" Tri Clamp Base with a 4" Sight Glass in the side to easily see your extraction. We added a 6" x 2" Tri Clamp Bowl to easily recover your extraction.

We use 304 Stainless Steel for durability and to be sanitary. Our Sight Glasses are made of Borosilicate Glass, proven to hold with hydrocarbon exposure. And our gaskets are made of Viton so they don't degrade.

Each Kit Includes:

  • (1) - 6" x 8" Tri Clamp Base
  • (1) - 6" x 2" Tri Clamp Bowl
  • (1) - 6" Single Hinge Tri Clamp/Clover
  • (1) - 6" Viton Gasket

Add accessibility and the ability to see what your producing with our Port Hole Sight Glass Kit Today!!!!

DETERMINING TRI CLAMP SIZE

Tri Clamp sizes are determined by the outer diameter of the pipe or tubing, not the outer diameter of the flange or Tri Clamp itself. The flange of a Tri Clamp fitting typically has about a ½” inch greater diameter than the outside diameter of the pipe. This can become especially confusing when the Tri Clamp fitting has no pipe attached to it, as is the case with adapters, For instance, a 1.5" Tri Clamp to 1/2" hose barb adapter is not 1.5" inches in any dimension, but the Tri Clamp end will fit any other 1.5" Tri Clamp fitting.

If you have any doubts about what size Tri Clamp fittings your project needs, simply measure the outside diameter of the flange (dimension "B" below) and consult the chart below, or feel free to contact us .





Pipe Outer Diameter
A

Flange Outer Diameter
B

Pipe Inner Diameter
C

Tri Clamp Dimension Diagram

1"

1.98"

.87"

1.5"

1.98"

1.37"

2"

2.52"

1.87"

2.5"

3.05"

2.37"

3"

3.58"

2.87"

4"

4.68"

3.83"

6"

6.57"

5.78"

8"

8.57"

7.78"

10"

10.57"

9.69"

12"

12.57"

11.81"
